Forklift 3 Ton

ModelFD30,FD20,FD25

Capacity3000kg,2000kg, 2500kg

1,676 3 ton caterpillar forklift products are offered for sale by suppliers on Alibaba.com, of which forklifts accounts for 5%. A wide variety of 3 ton caterpillar forklift options are available to you, such as 3 years, not available. Capacity: 1 ton, 2.5 ton, 2 ton, 3 ton. Lift Height: 2000-3000 mm, 1000-2000 mm, 3000-5000 mm. Our rapidly growing organization is busy in offering a premium quality.

Load center500mm

3 Ton Small Diesel Forklift Work In Container. 500mm load center, 1220mm fork length Xinchai Engine C490 Power Hydraulic transmission With hydraulic fork positioner 3000mm lifting height, two stage wide view mast Pneumatic tires (4/2) Send Inquiry. Product Details; 1. LED working lights and warning lights make it safer and more efficient even.
Stackers & Movers India Manufacturing Company - Offering 3 Ton Diesel Forklift, Model: CPCD 30/35 at Rs 750000/unit in Ahmedabad, Gujarat. Read about company. Get contact details and address ID: 8.
3 Ton Diesel Forklift By a combination of advanced designs and technologies, FLIFT forklifts with excellent quality and performance have become the designated essential equipment for domestic airports transportation and material handling.

Lift height3000mm

Fork size(LxWxH)1070*125*45mm,1070*120*40mm, 1070*120*40mm

We're here to help:Easy ways to get the answers you need.

3 Ton Diesel Forklift: By a combination of advanced designs and technologies, FLIFT forklifts with excellent quality and performance have become the designated essential equipment for domestic airports transportation and material handling.

Technical Parameters

Model	FD15	FD20	FD25	FD30	FD35
Brand(OEM acceptable)	FLIFT	FLIFT	FLIFT	FLIFT	FLIFT
Power Source	Diesel	Diesel	Diesel	Diesel	Diesel
Capacity	kg	1500	2000	2500	3000	3500
Load center	mm	500	500	500	500	500
Lift height（Duplex wide-view）	mm	3000	3000	3000	3000	3000
Fork size(LxWxH)	mm	92012035	107012045	107012040	107012545	107012550
Mast tilt angle(F/R)	Deg	6°/12°	6°/12°	6°/12°	6°/12°	6°/12°
Length to face of fork	mm	2295	2600	2600	2730	2770
Overall width	mm	1086	1150	1150	1225	1225
Mast lowered height	mm	1995	1995	1995	2045	2045
Mast extended height	mm	3940	4030	4030	4150	4150
Overhead guard height	mm	2040	2070	2070	2090	2090
Turning radius	mm	2055	2310	2310	2440	2480
Min. right angle aisle width	mm	2150	2380	2380	2490	2530
Front overhang	mm	420	470	470	475	480
Ground clearance	mm	110	120	120	135	135
Wheelbase	mm	1400	1600	1600	1700	1700
Travel (no load)	km/h	15	19	19	19	19
Lifting (full load)	mm/s	450	530	530	440	420
Gradeability(laden)	%	20	20	20	20	20
Service weight	kg	2820	3590	3790	4300	4500
Front tire	6.50-10-10PR	7.00-12-12PR	7.00-12-12PR	28x9-15-12PR	28x9-15-12PR
Rear tire	5.00-8-10PR	6.00-9-10PR	6.00-9-10PR	6.50-10-10PR	6.50-10-10PR
Battery (voltage/capacity)	v/ah	(12V/80Ah)	(12V/80Ah)	(12V/80Ah)	(12V/80Ah)	(12V/80Ah)
Engine model	C490BPG-236	C490BPG-236	C490BPG-236	NISSAN	A495BPG-13
Engine rated output/r.p.m	kw	40/2650	40/2650	40/2650	31.2/2250	42/2650
Engine rated torque/r.p.m.	n.m	160/1800-2000	160/1800-2000	160/1800-2000	143.7/1600	174/1800-2000
Engine No.of Cylinder	4	4	4	4	4
Bore x stroke	mm	95x105	95x105	95x105	89x83	95x105
Displacement	cc	2670	2670	2670	2065	2980
Fuel tank capacity	L	60	60	60	45	60

FEATURES

Small ton internal combustion forklift
Character:
1.Strong power system
2.Wide-view mast
3.Unique overhead guard design
4.Low non-slip pedal
5.Adjustable safety seat
6.Solid-state LCD digital meter
7.Eco-friendly design
8.Adjustable steering wheel
9.By a combination of advanced designs and technologies, FLIFT forklifts with excellent quality and performance have become the designated essential equipment for domestic airports transportation and material handling.

Warranty and continuous original spare parts supply:
14 months or 1500 work-hour warranty period:
Frame, drive axle, wheel, rim, brake, brake pump, steering axle, steering cylinder, hydraulic pump, speed limit valve, fork, lift cylinder, tilt cylinder, control valve, hydraulic pipeline, water tank.
12 months or 1200 work-hour warranty period:
Engine ,hydraulic gear box, battery, instrument panel. Fan belt, all switches, plate friction outside and inside, generator and starter.
Our staff of sales and technical support is available to help you in selecting the right forklift, we are committed to providing the highest level of customer service, competitive pricing, speedy delivery and a comprehensive product supplying. Our ultimate goal is your satisfaction！
